Rockwell Automation Publication 1441-UM001B-EN-P - September 2012 29
Chapter
2
Configuring the Dynamic 2500 Data Collector
This chapter describes what you need to do to configure the data collector.
Apply Power to the Data
Collector After connecting the data collector to AC power or installing the battery, a single
press of the On/Off key applies power to the instrument. However, to power off
the instrument you need to press On/Off for a period of one second. The
instrument resumes operation at the last screen you viewed when you powered off
the data collector.
Topic Page
Apply Power to the Data Collector 29
Installing the USB Drivers for the Data Collector 30
Updating the Operating System 34
Restarting the Data Collector 42
Dynamix 2500 Data Collector Main Menu 45
Dynamix 2500 Data Collector Setup Screen 48
Dynamix 2500 Data Collector Data Collection Screen 51
Setting Up the Dynamix 2500 Data Collector 55
Using Memory Cards 64
TIP The first time you turn on the Dynamix 2500 Data Collector or
following a reset, the Instrument Setup screen automatically appears.
See Set the Date, Time and Date Format on page 50 for more
information.
