Chapter 4
Loading and Unloading
– The Emonitor software loads the file into the data collector and a
second progress bar appears.
4.
When finished, click Close.
Display the Data Collector Driver Version Number
The data collector driver is the software that allows the Emonitor software to
communicate with the Dynamix. You can display the data collector driver version
number in the Emonitor software.
Follow these steps to display the version number.
1.
Select Tools > Load/Unload.
The Load/Unload dialog box appears.
2.
Make sure the correct data collector appears in the Set Up Collector.
3.
Click D.C. Function.
The Data Collector Function dialog box appears.
TIP
For details on displaying the data collector operating system version
number in the Dynamix 2500 Data Collector, see
