See the master parts list for the most up-to-date information:
Recommended Tools
The following list of tools is provided for your reference to disassemble and
assemble the drive and components. This list may not be all-encompassing for
your situation. Not all tools are needed for some components. See pertinent
sections for details.
Miscellaneous (continued)
Capacitor Bus Finger Kit
SK-G1-FLXBUS1
Included with the kit for Inverter
Power Module (IGBT).
Can be ordered separately.
Includes:
• Three positive Flexible Capacitor
Busbars
• Three negative Flexible Capacitor
Busbars
MOV Surge Suppressor
SK-G1-MOV1-F89
For AC input drives only.
Power Supply, 24V
SK-G9-PWRS24
Transformer, 500 VA
SK-G9-XFMR1-F89
For AC input drives only.
Includes:
• One Transformer
• Three fuses
Transformer Fuses
SK-G9-FUSE1-F8
For AC input drives only.
Includes three fuses.
Balancing Resistor
1336-RLOAD-SP3A
IMPORTANT
See the instruction sheet included with each component kit for
discarding or returning replaced components.
If discarding, be sure to discard according to local, state, and federal
regulations.
Description
Kit Catalog No.
Notes
Description
Torque wrench (metered in N•m or lb•in)
Volt ohm meter
Torque seal or colored marker
Screwdrivers (standard, Phillips, torx
–
various sizes)
Magnetic screwdriver, long
Socket set, metric
Cylindrical pick-up magnet
Pliers, regular and needle-nose
Wire cutters
Isopropyl alcohol and applicator cloth
Nylon tie wraps
3- or 4-inch paint roller with short nap or 3- or 4-inch putty knife (for installing SCR modules)
Pencil
