Rockwell Automation PF700 PowerFlex 700 Drive Components Replacement - Frame 9 User Manual
Page 31
Rockwell Automation Publication 20B-IN025B-EN-P - January 2011
31
Basic Component Removal Procedures Chapter 2
14.
Remove the Transitional Busbar unit.
Negative (DC-) Flexible
Capacitor Busbar (attached to
top side of Transitional Busbar)
Transitional Busbar Unit Removed
Positive (DC+) Flexible Capacitor
Busbar (attached to bottom side
of Transitional Busbar)
