Preface
Introduction
This publication provides guidelines for replacing the major components in the
PowerFlex 700 Frame 9 drive.
Component Kits
All kits include necessary components, ESD wrist strap and hardware (if
required), and thermal grease (if required).
Description
Kit Catalog No.
Notes
Printed Circuit Boards
Gate Interface Board
SK-G1-GDB1-F8910
Drive requires three kits
Precharge Board
SK-G9-PRE1-V480
AC input
1336-PB-SP22C
DC input
Power Interface Board
SK-G9-GDB1-D700
730 A
Main Control Board
SK-G9-VMCB1-D0
115V I/O
SK-G9-VMCB1-C0
24V I/O
T-Comm Board
SK-G9-TCOMM
Switch Mode Power Supply Board
SK-G9-PWRS1-D0
24V Power Supply Board (CTS)
SK-G9-PSR24
DC Bus Filter Board
2364-SPP02A
Fans and Main Fan Circuit Components
Heatsink Fan
SK-G1-FAN1-F9
Includes Fan and Fan enclosure
Capacitor Fan
SK-G1-FAN2-F8910
Power Module Sub-assemblies
Inverter Power Module (IGBT)
SK-G1-QOUT1-F910
Includes:
• One IGBT module
• One Gate Interface Board
• Gate Interconnect Harness
• Six Flexible Capacitor Busbars
• Three Snubber Capacitors
• One Tie Down Capacitor Mount
Drive requires three kits.
Converter Power Module (SCR)
SK-G1-SCR1-F89
For AC input drives only.
Kit includes three SCR Modules.
SCR Snubber Kit
SK-G1-SCRSNUBRB
AC input drive requires three kits.
DC input drive requires one kit.
DC Precharge SCR Module
SK-G1-SCR2-F89
For DC input drives only.
Includes:
• One SCR Module
• One Diode
DC Link Choke
SK-G1-DCCHOKE1-F9
For AC input drives only
Miscellaneous
Current Transducer
SK-G1-CT1-F910
Includes one Transducer.
Drive requires three kits.
Thermal Sensor Kit
SK-G1-THM1-F89
For AC input drives only.
Includes:
• Main Control Panel Thermal
Sensor
• Heatsink Thermal Sensor
SK-G1-THM2-F89
For DC input drives only.
Includes:
• Main Control Panel Thermal
Sensor
• Heatsink Thermal Sensor
Bus Capacitor Kit
SK-G1-BUSCAP1-F9
Includes one Capacitor.
Drive requires 18 kits.
