Waters IC-Pak Column and Guard - Manual

[ Care and Use ManUal ]
IC-Pak Column and Guard Column 1
Contents
I. IntroduCtIon
II. InstallatIon
III. eluent and sample guIdelInes
IV. operatIon
V. Care and maIntenanCe
VI. orderIng InformatIon
VII. Warranty/serVICe
IC-pak Column and guard Column
I. IntroduCtIon
Waters IC-Pak™ anion (A) and cation (C) columns are designed for use
in Ion Chromatography (IC) applications to separate ions.
a. Anion Columns
The stainless steel anion columns separate and quantify many
anions, such as F
- , CI - , NO
2
- , Br - , NO
3
- , HPO
4
2- , and SO
4
2- anions at
ppb levels. Table 1 lists the characteristics of IC-Pak anion columns.
Table 1: Anion Column Characteristics
The packing material is a polymethacrylate resin with a quaternary
ammonium functional group. The columns are shipped in 1.3 mM
gluconic acid/1.3 mM boric acid (pH 8.5).
b. Cation Columns
The non-metallic cation columns separate and quantify Li + , Na + ,
NH
4
+ , K + , Mg 2+ , Ca 2+ , Sr 2+ and Ba 2+ cations at ppb levels. The Waters
cation guard column, placed in the solvent stream before the
sample injector, is used only to aid monovalent cation detection by
removing polyvalent cations from the solvent stream.
Table 2 lists the characteristics of IC-Pak cation and cation guard
columns.
Anion Column Dimensions Particle Size Capacity
IC-Pak A 4.6 x 50 mm 10 µm 30 ± 3 µeq/mL
IC-Pak A HC
(High Capacity)
4.6 x 150 mm 10 µm 30 ± 3 µeq/mL
IC-Pak A HR
(High Resolution)
4.6 x 75 mm 6 µm 30 ± 3 µeq/mL
