184 • Replacing or Recharging the Batteries
Gas Tracer Operator’s Manual
If using a DC powered charging station, plug the 12 VDC vehicle
plug adapter into a vehicle’s 12 VDC power socket.
Figure 25: Connecting the Charging Station’s DC Adapter
The construction of the charging stations allows them to be chained
together but a separate adapter must be used for each charging
station. One adapter will not operate more than one charging
station.
To Vehicle
12 VDC
Power Socket
DC Adapter
Charge LED
DC Powered Charging Station
Power Supply Jack
