Gas Tracer Operator’s Manual Leak Testing • 115
Mode. See “Snap Logging Screen” on page 56 for more
information.
Viewing Snap Log Data in Leak Check Mode Operation
Snap log data can be viewed while in Leak Check Mode. If snap log
data was taken while in Normal Operation, that data will also appear.
1. Turn the Gas Tracer on as described in “Turning On the Gas Tracer,
Leak Check Mode” on page 101.
2. Press and hold the RESET SILENCE button and then press and
hold the DISPLAY (ADJ) button and release both.
3. If no snap logs have been performed, the following screen will
appear.
Press and release the DISPLAY (ADJ) button to return to Leak
Check Mode.
4. If snap logs have been performed in either Normal Operation or
Leak Check Mode Operation, one of the following screens will
appear. LEAK CK MODE will appear in the upper left corner of
Leak Check Mode Operation data to indicate that the snap log was
taken during Leak Check Mode Operation.
This screen indicates the year, month, day, and time that the most
recent snap log was taken. The number along the bottom of the
screen indicates the snap log ID number. The first snap log that is
taken is given an ID of M001. The next snap log ID is M002. The ID
NO DATA
2012
2
15
14:17
LEAK CK MODE
M009
2011
8
31
22:39
M023
Normal Operation Leak Check Mode Operation
Snap Log Snap Log
