SECTION 6. SPECIFICATIONS
Form 169441 20 Revision B
6 SPECIFICATIONS
HEADER MODEL D60 D50/D60 D60
HEADER SIZE 15 FT. 20 FT. 25 FT. 30 FT. 35 FT. 40 FT.
OVERALL
Width
(Inches (mm))
Transport (Reel Full
Aft) With CA20 Adapter
96 (2438)
Field
255.1
(6479)
315.1
(8003)
375.1
(9527)
435.1
(11051)
495.1
(12575)
Length
(Inches (mm))
Transport (with Tow Pole) Not Applicable
505.7
(12845)
547.5
(13907)
601.5
(15278)
Height - Transport 97 in. (2464 mm)
Estimated Weight Range
Base Header (lb (kg))
D50 Not Applicable 3500 (1589) 4150 (1884) 4700 (2134)
Not
Applicable
D60
3000
(1362)
3400
(1544)
3500 - 4100
(1589 - 1861)
4200 - 5100
(1907-2315)
4700 - 5700
(2134 - 2588)
5400 - 5800
(2451 - 2633)
CUTTERBAR
Width Inches (mm)
180
(4572)
240
(6096)
300
(7620)
360
(9144)
420
(10668)
480
(12192)
Header Cutting
Height
Shortest Center-Link
1.3 in. (32 mm) below ground -
52.3 in. (1328 mm) above
0.8 in. (20 mm) below ground -
52.8 in. (1340 mm) above
Longest Center-Link
4.6 in. (117 mm) below ground -
46.9 in. (1192 mm) above
4.1 in. (105 mm) below ground -
47.4 in. (1204 mm) above
Guard Angle (Cutterbar on Ground) 7.5° - 17.0° 2.5° - 12.0°
SICKLE
Drive Type
SK Not Applicable Hydraulic Motor / ‘C’ Belt/Heavy Duty (MD) Wobble Box
DK (Except D50)
Hydraulic Motor / Two ‘B’ Timing Belts /
Two Heavy Duty (MD) Wobble Boxes
Two
Hydraulic
Motors To
"C" Belts,
Untimed To
Heavy Duty
(MD) Wobble
Boxes
Sickle Speed
(Strokes Per Minute)
SK Not Applicable 1200 - 1500 1200 - 1400 1100 - 1300 1050 - 1200
DK (Except D50) 1500 - 1900 1400 - 1700 1200 - 1600 1200 - 1500 1100 - 1400
Stroke 3 in. (76 mm)
Sections -
Over-Serrated and
Bolted
(serrations/inch)
Cut-Out or Solid 14 9 / 14 9
Guards and
Hold-Downs
Pointed
D50 Not Applicable
Pointed / Case Hardened /
Sheet Metal / Adjuster Bolt
Not
Applicable
D60 Case Hardened or Double Heat Treated / Sheet Metal / Adjuster Bolt
Stub (Except D50) Sheet Metal HD
Sheet Metal
or
Forged HD
Not Applicable
