AP6/AP8 SERIES TRASH PUMPS • OPERATION AND PARTS MANUAL — REV. #0 (06/11/14) — PAGE 93
PUMP END ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 APRD24120 PLUG, 3/8" NPT BLACK STEEL 1
2 APRD24119 NIPPLE, GREASE 1/4" 1
3 APRD24117 BUSHING, REDUCING 3/8" X 1/4" 1
4 APRD24116 BACKPLATE, CAST IRON 1
5$#% APRD24142 SEAL, LIP 1
6% APRD24133 ENGINE STUB SHAFT SAE 10 1
7$#% APRD24132 KEY, IMPELLER 0.50"x3" 1
8 APRD24139 HHCS, 3/8X1-1/2 GRADE 5 PLTNC 8
9 APRD24140 WASHER, LOCK 3/8 " ZINC 8
10 APRD241291 ADAPTER, AP6TP. ENGINE MOUNT SAE4 1
10 APRD241292 ADAPTER, AP8TP, ENGINE MOUNT SAE3 1
11 APRD24147 HHCS, 1/2X1-1/4 GR 5 PLT NC 8
12$#%@ APRD24107 GASKET, VOLUTE 1
13 APRD24137 AHCS, 10M-1.5-35M 12
14 APRD24138 WASHER, LOCK 10M 12
15@ APRD24143 HHCS, 1/2" X1" 2
16@ APRD24102 CLEANOUT COVER, CAST IRON 1
17@ APRD24144 O-RING, 3/16CS X 3.88 ID BUNA 1
18@ APRD24104 PLUG, 1/2 " BLACK NPT 3
19@ APRD24103 VOLUTE 1
20 APRD24101 HHCS 5/8-11 X 1-1/2", GR 5, PLTNC 8
21#@ APRD24108 RING, WEAR 1
22$#% APRD24146 O-RING, 2.12 X 2.31 X .09 THICK 1
23$#% APRD24115 SLEEVE, SHAFT 1
24$#% APRD24105 SHCS, .75NC X 2.50 SS 1
25# APRD241091 IMPELLER, AP6TP, 10" TRIM 1
25# APRD241092 IMPELLER, AP8TP, 11" TRIM 1
26$% APRD24145 SHIM, MECHANICAL SEAL (IF NEEDED) 1
27$#% APRD24110 SEAL, MECHANICAL 2-1/2",TYPE 2 1
28 APRD241700 KIT, VOLUTE ........................................................ 1 ...........INCLUDES ITEMS W/@
29 APRD241800 KIT, SHAFT ......................................................... 1 ...........INCLUDES ITEMS W/%
30 APRD241600 KIT SEAL, IMPELLER, WEAR RING/MECH. ...... 1 ...........INCLUDES ITEMS W/#
31 APRD241500 KIT, MECHANICAL SEAL .................................... 1 ..........INCLUDES ITEMS W/$
