Table 11. Programmable Parameters
LED's
4
1
8
2
4
2
8
1
4
2
8
1 2
8
1
4
2
8 4
1 1
8 4
2
8 4
2 1
4 8
1 2
Parameter
Preheat
0-60 Sec.
or Ambient
Temp.
Number
Repeated
Starts 0-15
Pause
Between
Repeated
Starts 5-75
Seconds
Overcrank
2-30
Seconds or
Frequency
N/A
Engine
Cool-Down
Cycle
0-900
Seconds
Oil
Pressure
Switch NC,
NO, No
Switch
Oil
Pressure
Delay
Override
1-15 Sec.
LED's
4 8
2 1
4 8
1 2
4 8
2 1
8
2 1
4 8
2
4
1
8
1
4
2
8 4
2 1
8 4
2 1
Parameter
Auxiliary
Engine
Monitor
EP100,
MC536,
Solo
Starter
Motor
Disengage
Hz.
Turn On
Throttle
Control,
Compressor
etc.
Overspeed
Shutdown
Hz
Overspeed
Shutdown
Delay
Seconds
Engine
Warm-Up
Duration
8-38
Seconds
Standby
Mode
Consume
Electricity
Yes/No
Pass Code
#3 Digit
0-15
PROGRAMMING
1. Programming is accomplished by holding down the
OFF/SET button (Figure 33) on the MSS-200 for 2
seconds while energizing the controller. Energizing
the MSS-200 controller is accomplished by turning the
ignition key to the left position marked “ Auto Start”.
Figure 33. MSS-200 Controller Initialization
2. Releasing the OFF/SET button will bring you to
parameter 0, preheat duration indicated by the
flashing of LED 1 (Figure 34).
PRESS AND HOLD
FOR 2 SECONDS
OFF AUTO ST ART (WHEN EQ UIPPED)
RUN
Figure 34. Pre-Heat Duration (Blinking)
3. Pushing the OFF/SET button moves to each parameter
in ascending order and saves the programmed value.
The MAN button decreases the programmed value
while the AUTO button increases the programmed
value.
BLINKING
Pre-Heat Duration
NOTICE
The cool-down cycle and manual start functions can not
be used in the consumes-no-electricity mode.
PROGRAMMING
