AP6/AP8 SERIES TRASH PUMPS • OPERATION AND PARTS MANUAL — REV. #0 (06/11/14) — PAGE 117
CANOPY ASSY.
NO.
PART NO.
PART NAME
QTY.
REMARKS
1
APRD301011
FRONT DROP IN PANEL, AP6
1
1
APRD301012
FRONT DROP IN PANEL, AP8
1
2
APRD301021
TOP DOOR
1
3
APRD301031
SIDE DOOR
1
4
APRD301041
DISCHARGE PANEL LEFT SIDE, AP6
1
4
APRD301042
DISCHARGE PANEL LEFT SIDE, AP8
1
5
APRD301051
DISCHARGE PANEL RIGHT SIDE, AP6
1
5
APRD301052
DISCHARGE PANEL RIGHT SIDE, AP8
1
6
APRD301061
SUCTION DOOR LEFT SIDE, AP6
1
6
APRD301062
SUCTION DOOR LEFT SIDE, AP8
1
7
APRD301071
SUCTION DOOR RIGHT SIDE, AP6
1
7
APRD301072
SUCTION DOOR RIGHT SIDE, AP6
1
8
APRD30108
CANOPY HOLD DOWN LEFT-RIGHT REAR 1
8A
APRD301081
CANOPY HOLD DOWN FRONT LT. SIDE
1
8B
APRD301082
CANOPY HOLD BOWN FRONT RT. SIDE
1
10
APRD301101
CENTER PANEL, AP6
1
10
APRD301102
CENTER PANEL, AP8
1
11
APRD301111
REAR ROADSIDE CORNER PANEL, AP6........1................LEFT
11
APRD301112
REAR ROADSIDE CORNER PANEL, AP8........1................LEFT
12
APRD301121
REAR CURBSIDE CORNER PANEL, AP6 ........1................RIGHT
12
APRD301122
REAR CURBSIDE CORNER PANEL, AP6 ........1................RIGHT
13
APRD301131
FRONT ROADSIDE PANEL, AP6 ......................1................LEFT
13
APRD301132
FRONT ROADSIDE PANEL, AP8 ......................1................LEFT
14
APRD301141
FRONT CURBSIDE PANEL, AP6 ......................1................RIGHT
14
APRD301142
FRONT CURBSIDE PANEL, AP8 ......................1................RIGHT
15
APRD301151
CANOPY BOTTOM FRAME, AP6
1
15
APRD301152
CANOPY BOTTOM FRAME, AP8
1
20
APRD301201
FOOTER PANEL, AP6
2
20
APRD301202
FOOTER PANEL, AP8
2
20A
APRD3012011
HEADER PANEL, AP6
1
20A
APRD3012012
HEADER PANEL, AP8
1
21
APRD301211
TOP PANEL, AP6
1
21
APRD301212
TOP PANEL, AP8
1
30 APRD30130 HINGE
10
30A
APRD301301
SMALL HINGE
2
32
APRD30132
DOOR LATCH HANDLE
6
33
APRD30133
RADIATOR CAP
1
34
APRD301341
GRILL PANEL, AP6 ...........................................1................RIGHT
34
APRD301352
GRILL PANEL, AP8 ...........................................1................RIGHT
35
APRD301351
GRILL PANEL, AP6 ...........................................1................LEFT
35
APRD301352
GRILL PANEL, AP8 ...........................................1................LEFT
36
APRD301361
FRONT INNER WALL, AP6
1
36
APRD301362
FRONT INNER WALL, AP8
1
37
APRD301371
BOLT, 1/4-20 X 1" SS, AP6
66
37
APRD301372
BOLT, AP8
66
38
APRD301381
WASHER, FLAT AP6
66
38
APRD301382
WASHER, FLAT AP8
66
41 TBD
INSULATION
2
42
TBD
SCREW, PHILLIPS HEAD
8
43
TBD
WASHER, FLAT
8
