AP6/AP8 SERIES TRASH PUMPS • OPERATION AND PARTS MANUAL — REV. #0 (06/11/14) — PAGE 101
CONTROL BOX ASSY.
NO.
PART NO.
PART NAME
QTY.
REMARKS
1#$
APRD3132
GUAGE, PRESSURE 150 PSI
1
2# $
APRD3133
GUAGE, TEMP 250° F
1
3# $
APRD3133
NUT, KEP 5/16"-18 SS
6
4# $
APRD3137
WASHER, LOCK 5/16" SS
3
5# $
APRD3136
ISOLATOR, EP250 PANEL 5/16"
3
6# $
APRD3139
KEY
1
7# $
APRD31310
SWITCH, IGNITION W/2 KEYS
1
8# $
APRD3134
TACHOMETER, VDO 4000 RPM
1
9# $
APRD31311
HOURMETER, ANALOG VDC VDO
1
10# $ APRD31313
FACE PLATE ......................................................1................INCLUDES 6 LEDS
11# $ APRD31314
LANYARD
1
12# $ APRD3138
MOUNTING BRACKET
1
13# $ APRD3131
VOLTMETER, 12 VOLT
1
14 $
R48PW12D
ALARM, AUDIBLE
1
15 $
R48201020000
MSS-200 AUTO-START COMTROLLER
1
16
APRD313A
CONTROL BOX, COMPLETE, MANUAL ..........1................INCLUDES ITEMS W/#
16
R52EP25017000 CONTROL BOX, COMPLETE, AUTOSTART ....1................INCLUDES ITEMS W/$
