MSS-200 DIAGNOSTICS (MANUAL MODE)
Reference Table 14 for a brief explanation of the LED status
indicators when MSS-200 is in MANUAL mode.
Table 14. MSS-200 LED Status Manual Mode
LED's Description
1 2
4 8
Automatic self test. The MSS-200 is turned on. System is energized.
1 2
8 4 The MSS-200 is in off position and is awaiting a manual start signal Pushing MAN button will
start engine. Changing to AUTO mode is possible by pressing the AUTO button.
8
2
4
1
Engine is preheating.
8
2
4
1
Engine is starting.
4
1 2
8
Engine is running via the manual mode. If programmed engine will go into cool down cycle when
the OFF/SET button is pushed 1 time. Engine will stop immediately when the OFF/SET button is
pushed 2 times.
8
1 2
4 Engine is the cooling down cycle. Engine will shut down after it runs without a load for the
programmed amount of time.
