Appendix
Index table
10
l
143 KHB 13.0002−EN 4.1
Characteristics Possible settings Name Index
Description Selection Lenze
60FF
h
0 target_velocity 0 −2 31 {1 rpm} 2 31 −1 VAR INT32 RW MAP
Setting of the setpoint
selected for the ramp
generator.
The unit can be set via the
factor group.
6410
h
0 motor_data REC UINT8 RO Ċ
Reading−out of the motor
data.
3 iit_time_motor 2000 0 {1 ms} 10000 Ċ UINT16 RW Ċ
Setting of the time interval
for which the motor can be
fed with I
max
(index 6073
h
).
When this time has expired,
the motor is automatically
limited to the value set
under 6075
h
.
4 iit_ratio_motor {1 ‰} Ċ UINT16 RO MAP
Reading−out of the actual
utilisation ratio of the I
2 t
limitation.
10 phase_order 1 0 {1} 1 Ċ UINT16 RW MAP
Setting of the phase
sequence.
See ’angle encoder’ dialog
box in the SDC
parameterisation program.
0 Phase sequence: left
1 Phase sequence: right
11 resolver_offset_
angle
11360 −32767 {1 inc} 32767 Ċ INT16 RW MAP
Setting of the angle encoder
orientation with respect to
the permanent magnetic
field of the rotor.
See ’angle encoder offset
angle’ dialog box in the SDC
parameterisation program.
Conversion:
a = offset angle
× 32767/180°
= 11360 (with offset angle
= 62.4°)
