Operating modes
Synchronous position selection
Functional description
9
l
115 KHB 13.0002−EN 4.1
Characteristics Possible settings Name Index
Description Selection Lenze
60C4
h
0 interpolated_data_
configuration
REC UINT8 RO Ċ
Reading−out of the buffer.
1 max_buffer_size Ċ UINT32 RO MAP
Reading−out of the size of
the position buffer for
interpolated position mode.
2 actual_buffer_size 0 0 {1} 2 32 −1 Ċ UINT32 RW MAP
Size of the actual position
buffer for interpolated
position mode.
3 buffer_
organization
0 0 {1} 255 Ċ UINT8 RW MAP
Type of the buffer.
0 FIFO
4 buffer_position 0 0 {1} 65535 Ċ UINT16 RW MAP
Access to the buffer.
5 size_of_data_
record
2 1 {1} 255 Ċ UINT8 WO MAP
Size of one buffer element.
6 buffer_clear 0 0 {1} 1 Ċ UINT8 WO MAP
Access to the buffer.
Although there is no buffer
available for the "linear
interpolation without
buffer" interpolation type,
access must also be enabled
in this case.
0 Clear buffer / access to
60C1
h
not enabled
1 Access to 60C1
h
enabled
9.5.3 Functional description
Before the drive controller can be switched to the interpolated position mode operating
mode, several settings have to be made.
These settings include the interpolation interval (interpolation_time_period), i.e. the time
interval between two sync telegrams, and the interpolation type
(interpolation_submode_select). Additionally, access to the position buffer must be
enabled via the buffer_clear object.
