Safety engineering
Safe bus interfaces
PROFIsafe connection
1
l
97 EDS94AYAE EN 7.0
Bit coding of PROFIsafe input data
Bit Name Description
0 STO active The STO function is active and the drive is safely switched to torque−free
operation.
This bit is also set at the end of the stopping time by SS1.
1 SS1 active The SS1 function is active.
At the end of the function the STO bit is set.
2 SS2 active The SS2 function is active.
At the end of the function the SOS bit is set.
3 SLS1 active The SLS1 function is active.
When the braking time has elapsed, the SLS1_monitored bit is set
additionally.
4 SLS2 active The SLS2 function is active.
When the braking time has elapsed, the SLS2_monitored bit is set
additionally.
(From SM301 V1.1 onwards)
5 SLS3 active The SLS3 function is active.
When the braking time has elapsed, the SLS3_monitored bit is set
additionally.
(From SM301 V1.1 onwards)
6 SLS4 active The SLS4 function is active.
When the braking time has elapsed, the SLS4_monitored bit is set
additionally.
(From SM301 V1.1 onwards)
7 SDIpos is active The SDIpos function is active.
After the deceleration time has expired, bit 21 (SDIpos monitored) is set in
addition.
(As of SM301 V1.3)
8 SDIneg is active The SDIneg function is active.
After the deceleration time has expired, bit 22 (SDIneg monitored) is set in
addition.
(As of SM301 V1.3)
9 ES active 1: ES function in special operation is active: Motion function
0: ES function in special operation is not active: Stop function
10 SLI is active The safely limited increment (SLI) function is active. (As of SM301 V1.4)
11 OMS 1: special operation requested
0: normal operation
16 SOS monitored The SOS function is monitored.
17 SLS1 monitored The SLS1 function is monitored.
18 SLS2 monitored The SLS2 function is monitored. (from SM301 V1.1)
19 SLS3 monitored The SLS3 function is monitored. (from SM301 V1.1)
20 SLS4 monitored The SLS4 function is monitored. (from SM301 V1.1)
21 SDIpos is monitored The SDIpos function is active, the compliance with the direction of
movement is monitored.
(As of SM301 V1.3)
22 SDIneg is monitored The SDIneg function is active, the compliance with the direction of
movement is monitored.
(As of SM301 V1.3)
23 SSE active The SSE function is monitored.
When the stopping time has elapsed, the STO or SS1 bit is set according to
the emergency stop function parameterised.
24 SD−In1 Sensor at I1A and I1B Channels A and B are in the ON state
25 SD−In2 Sensor at I2A and I2B Channels A and B are in the ON state
26 SD−In3 Sensor at I3A and I3B Channels A and B are in the ON state
27 SD−In4 Sensor at I4A and I4B Channels A and B are in the ON state
29 OMS active Special operation is not active. (from SM301 V1.1)
31 Error active Error status (i.e trouble or warning) is active.
Tab. 1−12 Detailed specification of the PROFIsafe input data
