Safety engineering
Appendix
Module internal codes
1
l
129 EDS94AYAE EN 7.0
Index: Data type: Name: Parameter:
C15800 Current error type UNSIGNED_8 8775 d = 2247 h
Type of the currently pending error
Selection list (read only) Information
0 No error
1 Warning
2 Trouble
þ Read access o Write access o Controller inhibit o PLC-STOP o No transfer
C15801 Error history UNSIGNED_16 8774
d
= 2246
h
for Lenze service
Selection list (read only) Information
− − − (As of SM301 V1.2)
Subcodes Information
C15801/1 − Error history 1
...
C15801/8 − Error history 8
þ Read access o Write access o Controller inhibit o PLC-STOP o No transfer
C15805 Service code UNSIGNED_32 8770
d
= 2242
h
for Lenze service
Selection list (read only) Information
− − − (From SM301 V1.2)
Subcodes Information
C15805/1 − −
C15805/2 − −
C15805/3 − −
þ Read access o Write access o Controller inhibit o PLC-STOP o No transfer
C15810 Service code UNSIGNED_32 8765
d
= 223D
h
for Lenze service
Selection list (read only) Information
− − − (From SM301 V1.2)
Subcodes Information
C15810/1 − −
...
C15810/11 − −
þ Read access o Write access o Controller inhibit o PLC-STOP o No transfer
C15815 Service code UNSIGNED_16 8760
d
= 2238
h
for Lenze service
Selection list (read only) Information
− − − (From SM301 V1.3)
þ Read access o Write access o Controller inhibit o PLC-STOP o No transfer
C15820 Internal actual position value INTEGER_32 8755 d = 2233 h
for Lenze service
Selection list (read only) Information
− − − (From SM301 V1.3)
Subcodes Information
C15820/1 − Internal actual position value pSM
C15820/2 − Internal actual position value pGG
þ Read access o Write access o Controller inhibit o PLC-STOP o No transfer
