Module internal codes
1
l
119 EDS94AYAE EN 7.0
Index: Data type: Name: Parameter:
C15052 SD-Out condition BITFIELD_32 9523 d = 2533 h
Bit coded selection of the conditions for switching the safe output.
Value is bit coded: Information
Bit 0 SOS monitored Safe operational stop is monitored.
Bit 1 SOS monitors neg. logic Safe operational stop is not monitored.
Bit 2 SLS1 monitored Safely limited speed 1 is monitored.
Bit 3 SLS1 monitored neg. logic Safely limited speed 1 is not monitored.
Bit 4 SLS2 monitored Safely limited speed 2 is monitored. (from SM301 V1.1)
Bit 5 SLS2 monitors neg. logic Safely limited speed 2 is not monitored. (from SM301 V1.1)
Bit 6 SLS3 monitored Safely limited speed 3 is monitored. (from SM301 V1.1)
Bit 7 SLS3 monitors neg. logic Safely limited speed 3 is not monitored. (from SM301 V1.1)
Bit 8 SLS4 monitored Safely limited speed 4 is monitored. (from SM301 V1.1)
Bit 9 SLS4 monitors neg. logic Safely limited speed 4 is not monitored. (from SM301 V1.1)
Bit 10 SDIpos monitored Safe positive direction is monitored. (from SM301 V1.3)
Bit 11 SDIpos monitors neg. logic Safe positive direction is not monitored. (from SM301 V1.3)
Bit 12 SDIneg monitored Safe negative direction is monitored. (from SM301 V1.3)
Bit 13 SDIneg monitors neg. logic Safe negative direction is not monitored.
(from SM301 V1.3)
Bit 14 SSE active Emergency stop function
Bit 15 SSE active neg. logic
Bit 16 SD−In1 active Safe inputs
Bit 17 SD−In1 active neg. logic
Bit 18 SD−In2 active
Bit 19 SD−In2 active neg. logic
Bit 20 SD−In2 active
Bit 21 SD−In2 active neg. logic
Bit 22 SD−In4 active
Bit 23 SD−In4 active neg. logic
Bit 24 Reserved
Bit 25 Reserved
Bit 26 OMS active Special operation is active (from SM301 V1.1)
Bit 27 OMS active neg. logic Special operation is not active (from SM301 V1.1)
Bit 28 Reserved
Bit 29 Reserved
Bit 30 Error active
Bit 31 Error active neg. logic
Subcodes Information
C15052/1 SD-Out1 switching condition
þ Read access } Write access o Controller inhibit o PLC-STOP o No transfer
C15055 SD−Out logic function UNSIGNED_8 9520
d
= 2530
h
Selection of the logic operation for the switching conditions to be evaluated
Selection list (Lenze setting bold) Information
0 OR
1 AND
Subcodes Information
C15055/1 SD−Out1 logic function
þ Read access } Write access o Controller inhibit o PLC-STOP o No transfer
