Module internal codes
1
l
120 EDS94AYAE EN 7.0
Index: Data type: Name: Parameter:
C15060 Output image BITFIELD_16 9515 d = 252B h
Output image of the safety module feedback, shown in channels.
Value is bit coded: Information
Bit 0 SD-Out1 channel A
Safe output 1
Bit 1 SD-Out1 channel B
Bit 2 reserved
...
Bit 15 reserved
þ Read access o Write access o Controller inhibit o PLC-STOP o No transfer
C15100 S bus: Configuration UNSIGNED_8 9475
d
= 2503
h
Configuration of the safety bus
Selection list (Lenze setting bold) Information
0 No safety bus
1 PROFIsafe / PROFIBUS
2 PROFIsafe / PROFINET (As of SM301 V1.1)
þ Read access } Write access o Controller inhibit o PLC-STOP o No transfer
C15101 Display − DIP switch position UNSIGNED_16 9474
d
= 2502
h
Display of the DIP switch position
Display area (min. value | unit | max. value) Information
0 1023
þ Read access o Write access o Controller inhibit o PLC-STOP o No transfer
C15111 Safety address UNSIGNED_16 9464 d = 24F8 h
Safety address parameterised in the safety module
Setting range (min. value | unit | max. value) Information
0 65534 Lenze: 0
þ Read access } Write access o Controller inhibit o PLC-STOP o No transfer
C15112 Effective safety address UNSIGNED_16 9463
d
= 24F7
h
Address used in safety module
Display area (min. value | unit | max. value) Information
1 65534
þ Read access o Write access o Controller inhibit o PLC-STOP o No transfer
