Safety engineering
Safety address
1
l
89 EDS94AYAE EN 7.0
Codes
Parameter: Name: Data type: Index:
C15017 Stored module ID UNSIGNED_16 9558 d = 2556 h
Module ID stored in the safety module
Display area (min. value | unit | max. value) Information
0 65535 (As of SM301 V1.2)
Default setting (invalid ID): 0
Stored ID defective: 65535
þ Read access o Write access o Controller inhibit o PLC-STOP o No transfer
C15101 Display − DIP switch position UNSIGNED_16 9474
d
= 2502
h
Display of the DIP switch position
Display area (min. value | unit | max. value) Information
0 1023
þ Read access o Write access o Controller inhibit o PLC-STOP o No transfer
C15111 Safety address UNSIGNED_16 9464 d = 24F8 h
Safety address parameterised in the safety module
Setting range (min. value | unit | max. value) Information
0 65534 Lenze: 0
þ Read access } Write access o Controller inhibit o PLC-STOP o No transfer
C15112 Effective safety address UNSIGNED_16 9463
d
= 24F7
h
Address used in safety module
Display area (min. value | unit | max. value) Information
1 65534
þ Read access o Write access o Controller inhibit o PLC-STOP o No transfer
