Safety engineering
Device modules
Safe inputs
1
l
30 EDS94AYAE EN 7.0
1.2.4 Safe inputs
1.2.4.1 General
The following applies to the sensors at the SM301 V1.0:
ƒ Sensor type and sensor function can be parameterised in C15030, C15031 and
C15032.
ƒ A local evaluation is executed if corresponding parameters are set.
ƒ If a safety bus is activated, the sensor signals are sent as status information to the
higher−level control.
ƒ Deactivated sensor inputs must not be connected. The status of a non−connected
input is in the OFF state.
ƒ If a signal is detected at deactivated sensor inputs during initialisation, the drive
remains inhibited (STO).
ƒ Faulty inputs are assessed as OFF state.
Additional conditions from SM301 V1.1 onwards:
ƒ With active cascading in C15035 the SD−In4 input cannot be used freely anymore.
Codes
Parameter: Name: Data type: Index:
C15030 SD-In sensor type UNSIGNED_8 9545
d
= 2549
h
Configuration of the sensor types which are connected to the safe inputs.
Selection list (Lenze setting bold) Information
0 Input deactivated
1 Passive sensor
2 Active sensor
Subcodes Information
C15030/1 SD-In1 sensor type
C15030/2 SD-In2 sensor type
C15030/3 SD-In3 sensor type
C15030/4 SD-In4 sensor type
þ Read access } Write access o Controller inhibit o PLC-STOP o No transfer
C15031 SD-In sensor function UNSIGNED_8 9544 d = 2548 h
Function configuration of the safe inputs.
l The "operation mode selector" and "enable switch" functions may only be assigned to one of the four safe
inputs.
Selection list (Lenze setting printed in bold) Information
0 Free assignment Safety function set in C15032
1 Emergency stop Safe stop emergency function (SSE)
2 Operation mode selector Safe operation mode selector (OMS)
3 Enable switch Safe enable switch (ES)
Subcodes Information
C15031/1 SD-In1 sensor function
C15031/2 SD-In2 sensor function
C15031/3 SD-In3 sensor function
C15031/4 SD-In4 sensor function
þ Read access } Write access o Controller inhibit o PLC-STOP o No transfer
