Safety engineering
Appendix
Module internal codes
1
l
132 EDS94AYAE EN 7.0
Index: Data type: Name: Parameter:
8682 d = 21EA h BITFIELD_64 Log state C15893
Bit 48 FailSafeValues via control word Safe replacement values on the safety bus were
activated via the control word.
Bit 49 FailSafeValues through error Safe replacement values on the safety bus were
activated through an error.
Bit 50 Reserved −
Bit 51 Reserved −
Bit 52 SD−In1 active The safe input SD−In1 has been switched on.
Bit 53 SD−In2 active The safe input SD−In2 has been switched on.
Bit 54 SD-In3 active The safe input SD−In3 has been switched on.
Bit 55 SD−In4 active The safe input SD−In4 has been switched on.
Bit 56 Reserved −
...
Bit 63 Reserved −
Subcodes Information
C15893/1 Log state n
C15893/2 Log state n−1
...
C15893/10 Log state n−9
þ Read access o Write access o Controller inhibit o PLC-STOP o No transfer
C15900 Firmware − product type VISIBLE_STRING 8675
d
= 21E3
h
Display of the product type (E94AFAE)
þ Read access o Write access o Controller inhibit o PLC-STOP o No transfer
C15901 Firmware − compilation date VISIBLE_STRING 8674
d
= 21E2
h
Display of the compilation date
þ Read access o Write access o Controller inhibit o PLC-STOP o No transfer
C15902 Firmware version VISIBLE_STRING 8673 d = 21E1 h
Software version of the firmware, e.g.: "V1.0"
þ Read access o Write access o Controller inhibit o PLC-STOP o No transfer
