1.10.2 Module error messages
The Parameterisation & Configuration Software Manual provides information on
diagnostics & fault analysis and describes the structure of the operating system’s error
messages in the logbook.
Entries
Field Description Error type/response/
Note
Error number
Internal
1 0x01 Internal error, STO is active Replace safety module.
Consultation with Lenze is
required.
2 0x02 Internal error, SS1 is active
3 0x03 Internal error, SS2 is active
Communication − standard device
16 0x10 Communication error − standard device
(communication between standard device and SM301 cancelled) Warning/STO
17 0x11 Synchronisation error − standard device No error status
Logbook entry/info
PROFIsafe
33 0x21 Safety address is invalid (0 or 0xFFFF)
34 0x22 PROFIsafe communication error
PROFIsafe passivated/−
No error status
No diagnostic telegram via
PROFIBUS
35 0x23 F_WD_Time exceeded
(PROFIsafe monitoring time activated)
36 0x24 PROFIsafe deactivated
37 0x25 PROFIsafe has quit Data Exchange
38 0x26 PROFIsafe invalid data
39 0x27 Error − F parameter
(Wrong parameter setting of the F PLC) PROFIsafe parameter
setting/STO
No error status
40 0x28 Communication error in parameter phase
Inputs
49 0x31 Error − discrepancy or functional test SD−In1
Trouble/−
OFF state for the affected
input
50 0x32 Error − discrepancy or functional test SD−In2
51 0x33 Error − discrepancy or functional test SD−In3
52 0x34 Error − discrepancy or functional test SD−In4
53 0x35 Internal error AIS
54 0x36 Internal error AIE
55 0x37 Internal error − module switch
57 0x39 Deactivated SD−In1 = high
(Initialisation error, input in ON state)
Trouble/STO
58 0x3A Deactivated SD−In2 = high
59 0x3B Deactivated SD−In3 = high
60 0x3C Deactivated SD−In4 = high
