Specifications
Specifications
Specification
Conventional Hoppers
bulk Fill
Number of Rows
12R 30
16R 30
24R 30
12R 30
16R 30
24R 30
Row Spacing
30"
30"
30"
30"
30"
30"
Weight Empty (Vacuum Meter)
16,370 lb
20,810 lb
30,875* lb
17,070 lb
21,490 lb
31,525* lb
*add 165 lb for optional flip axle (24R only)
Transport Height
(with optional row marker package)
11'-7"
11'-7"
11'-7"
11'-7"
11'-9"
12'-0"
Planting Height
8'-8"
8'-8"
8'-8"
8'-9"
8'-11"
9'-3"
Planting Length
20'-3"
21'-8"
28'-8"
20'-3"
21'-8"
28'-8"
Transport Length
26'-11"
33'-5"
43'-8"
26'-11"
33'-5"
43'-8"
Planting Width
32' -0"
43'-9"
62'-4"
32' -0"
43'-9"
62'-4"
Transport Width (14'-0" with granular
chemical option)
11'-4"
12'-0"
12'-0"
11'-4"
12'-0"
12'-0"
Seed Capacity
1.90 bu. / 3.0 bu.
90 bu.
120 bu.
120 bu.
Bulk Fill Dimensions
(planting position height)
9' 4"
Transport Tire Size (4)
255-70R
22.5
41" x 11" R
22.5
41" x 11" R
22.5
255-70R
22.5
41" x 11" R
22.5
41" x 11" R
22.5
Transport Tire Pressure
100 psi
75 psi
75 psi
100 psi
75 psi
75 psi
Wing Tires
7.5" x 20"
(2)
7.5" x 20"
(4)
41" x 11" R
22.5 (4)
7.5" x 20"
(2)
7.5" x 20"
(4)
41" x 11" R
22.5 (4)
Field Tire Pressure
40 psi
40 psi
60 psi
40 psi
40 psi
60 psi
Piston Pump Drive Tires (Optional)
(2) 7.60" x 15"
Field Lift
12R - Four Master/Two Slave Hydraulics
16R/24R - Four Master/Four Slave Hydraulics
Row Markers
Independently controlled, three stage fold, disk blade depth bands.
