Machine Operation
FIELD TO TRANSPORT SEqUENCE USING ISObUS
Position planter in a relatively flat open area without furrows, etc.
SUMMARIzED FIELD TO TRANSPORT SEqUENCE
USING ISObUS VIRTUAL TERMINAL
NOTICE
Folding planter without using tractor to assist may cause equipment damage
especially in soft conditions or when loaded with seed or fertilizer. Use tractor
to reduce stress on frame, drive, and transport components.
1. Place planter into field turnaround position.
2. Lift drawbar or 2-point hitch to level planter frame.
3. Fold wings in toward tractor. When 2 hooks are over the top of the
inner hitch, the planter is fully folded.
4. Lift drawbar or 2-point hitch to lock wings into place after folding.
5. Raise transport axle to transport height or, if equipped with flip
axle, roll tires into rest position.
6. Raise wing wheels into transport position.
7. Install locking pin on drawbar hitch.
NOTE: Read following information for detailed instructions.
