Kinze 4900 Front Folding Planter Rev. 5/14 - Manual (Page 64)

M0247-01 Model 4900
TM
Row Unit Operation
3-6 Rev. 5/14
FIELD OPERATION
NOTE: Adjust down pressure with planter lowered and row openers in ground for most accurate adjustment.
Pressure can be adjusted using your ISObUS monitor. Refer to the ISObUS manual for more information.
ADJUST DOWN PRESSURE FROM CAB
Use the ISOBUS monitor to adjust down pressure. Refer to your ISOBUS manual for more information.
Air Compressor
Pressure gauge
MANUAL RUN bUTTON
Use the manual run button to turn on seed meter, fertilizer and insecticide on each row unit to check functionality.
