Machine Operation
6. (If applicable) Install PTO pump onto tractor PTO shaft. Make sure shaft rotation matches direction indicated on
pump housing.
NOTICE
Clean and grease PTO shaft coupling with high-pressure industrial
coupling grease (Chevron
®
coupling grease or equivalent) meeting
AGMA CG-1 and CG-2 Standards each time driveshaft is installed or
premature wear and equipment failure can occur.
Color and Label
Machine Function
Hose Size
Hose Function
Red AA
Field Lift
½
"
Pressure/Return
Red BB
½
"
Pressure/Return
Blue AA
Planter Fold & Row Marker
⅜
"
Pressure/Return
Blue BB
⅜
"
Pressure/Return
Black RR
Power Pack
5
/8
Return
Black PP
½
"
Pressure
Orange CD
⅜
"
Case Drain
Yellow RR
Bulk Fill System Pressure Fan
(Hydraulic Weight Transfer)
5
/8"
Return
Yellow PP
½
"
Pressure
Orange CD
⅜
"
Case Drain
Green RR
Vacuum Meter Fans
5
/8"
Return
Green PP
½
"
Pressure
Orange CD
⅜
"
Case Drain
7. If equipped with ISOBUS system, attach ISO connector.
8. For planters not equipped with ISOBUS, connect ASABE Standards 7 terminal connector for safety/warning
lights on planter to ASABE Standards receptacle on tractor. If your tractor is not equipped with an ASABE
Standards receptacle, check with your tractor manufacturer for availability. Check warning lights on planter work in
conjunction with warning lights on tractor.
9. Completely raise parking stands to prevent damage to stands and equipment when moving planter.
10. (If applicable) Connect compressor harness.
NOTE: A tractor model-specific PTO mount kit is required and available from GnL Engineering (319-227-7222
or gnlengineering.net) and Rowe Manufacturing (800-544-4123 or rowemfg.com).
