Kinze 4900 Front Folding Planter Rev. 5/14 - Manual (Page 106)

M0247-01 Model 4900
6-24 Rev. 5/14
TM
Lubrication and Maintenance
NOTE: Light packages supplied on Model 4900 Front Folding Planters meet ASAbE Standards. Check with
tractor manufacturer for correct wiring harness to be wired into lights on your tractor.
*Optional customer-supplied auxiliary lights and wires may be wired into existing plug terminals.
ELECTRICAL WIRING DIAGRAM
ISO Extension Cable
Hitch Hydraulic Blocks
(if applicable)
B A B A
Lights Cable
ISO Draft Link Cable
Auxiliary Cables
Row Modules
Main Can/Power Cable
Row Modules
