Lubrication and Maintenance
RIGHT AUXILIARY CAbLE
P/N A19414
Signal
Wire
Gauge
Color
MMR
WLR
AUXR
W3
W4
AX2
JS
SCL
PL
FRT
BFF
Solenoid Power
(12VDC)
10
Red
3
-
1
1
1
1
-
-
-
8
1
Worklight Power
(12VDC)
14
Red/White
1
2
-
-
-
-
-
-
1
-
-
Tow Light Power
(12VDC)
14
Red/Black
4
-
-
-
-
-
-
-
2
-
-
Sensor Supply +5VDC
16
White
7
-
3
-
-
-
-
-
-
-
-
Sensor Supply
+12VDC
16
White/Red
8
-
6
-
-
-
1
1
-
4
4
Ground
10
Black
2
-
7
-
-
-
2
2
-
5
5
Fertilizer Rate+
16
Orange
21
-
-
-
-
-
-
-
-
1
-
Fertilizer Rate-
16
Green
22
-
-
-
-
-
-
-
-
2
-
Fertilizer Flow Signal
16
Blue
23
-
-
-
-
-
-
-
-
6
-
Fertilizer Tank Level
16
Green/White
24
-
-
-
-
-
-
-
-
3
-
Fertilizer On/Off
16
Yellow
25
-
-
-
-
-
-
-
-
7
-
Axle
16
Blue/Black
20
-
-
-
-
2
-
-
-
-
-
Wing Wheels Right
16
Purple/Black
10
-
-
2
2
-
-
-
-
-
-
Right Vac PWM
16
Pink
28
-
2
-
-
-
-
-
-
-
-
Right Vac Signal
16
Tan
29
-
8
-
-
-
-
-
-
-
-
Bulk Fill Fan PWM
16
Pink/Green
11
-
-
-
-
-
-
-
-
-
2
Bulk Fill Fan Signal
16
Tan/Green
12
-
-
-
-
-
-
-
-
-
6
Right Toolbar
Position Signal
16
Green/Red
6
-
4
-
-
-
-
-
-
-
-
Jump Start Signal
16
Green/
Yellow
5
-
-
-
-
-
3
-
-
-
-
Tail Light
16
Brown/Black
19
-
-
-
-
-
-
-
8
-
-
Right Flasher
16
Green/Black
17
-
-
-
-
-
-
-
7
-
-
Left Flasher
16
Yellow/Black
16
-
-
-
-
-
-
-
6
-
-
Work Light Wing
16
Gray
14
1
-
-
-
-
-
-
-
-
-
Work Light Center
16
Gray/Black
15
-
-
-
-
-
-
-
4
-
-
Planter Lights
(PL)
Jump Start (JS)
Scale (SCL)
Bulk Fill Fan (BFF)
Fertilizer (FRT)
Right Auxiliary (AUXR)
Master Module Right
(MMR)
Right Work Light
(WLR)
Wing Wheel (W4)
Wing Wheel W3
Axle (AX2)
