Lubrication and Maintenance
CAN POWER CAbLE
P/N A19396
Signal
Wire
Gauge
Color
MM
SCL
F1
RM1
F2
RM2 F3
RM3 TERM
Power
8
Red
S
-
A
-
A
-
A
-
-
Ground
8
Black
U
-
-
3
-
3
-
3
-
Fused Power 1
16
Red/Yellow
-
-
B
4
-
-
-
-
-
Fused Power 2
16
Red/Yellow
-
-
-
-
B
4
-
-
-
Fused Power 3
16
Red/Yellow
-
-
-
-
-
-
B
4
-
CAN H
18 TP
Yellow
W
1
-
2
-
2
-
2
1
CAN L
18 TP
Green
V
2
-
5
-
5
-
5
2
RM Enable 1
16
Tan
-
-
B
1
-
-
-
-
-
RM Enable 2
16
Orange
-
-
-
6
-
1
-
-
-
RM Enable 3
16
Blue
-
-
-
-
-
6
-
1
-
Master Module
(MM)
F1
Fuse
15A
Terminator
(TERM)
Scale (SCL)
Row Module (RM)
Row Module (RM2)
Row Module (RM3)
F2
Fuse
15A
F3
Fuse
15A
