Page 117
TM
Model 4900
M0247-01
Rev. 5/14
6-35
Lubrication and Maintenance
FERTILIzER CONTROL CAbLE
Shut-off (SO)
Master Module (MM)
Flow Meter (FM)
Level Switch (LS)
(CV)
P/N A19421
Signal
Wire Gauge
Color
MM
LS
FM
SO
CV
Rate Increase
16
Orange/Red
1
-
-
-
1
Rate Decrease
16
Orange/Black
2
-
-
-
2
Sensor Supply 12VDC
16
Red/White
4
1
A
-
-
Ground
16
Black
5
3
C
-
-
Flow Meter Signal
16
Green
6
-
B
-
-
Level Switch
16
White
3
4
-
-
-
Solenoid Power
16
Red
8
-
-
1
-
Shut-off
16
Yellow
7
-
-
2
-
