Kinze 4900 Front Folding Planter Rev. 5/14 - Manual (Page 61)

TM
Model 4900 M0247-01
Rev. 5/14 3-3
Row Unit Operation
Seed hoppers have a capacity option of 1.9 or 3.0 bushels.
NOTE: Planters with the insecticide option are
required to use only the 1.9 bushel hoppers.
Use clean seed and make certain there are no foreign objects
inside when filling seed hopper.
Replace hopper lids after
hoppers are filled to prevent accumulation of dust or dirt
in seed meter which can cause premature wear.
Periodically empty hoppers completely to remove any foreign
objects and to ensure proper seed meter operation.
SEED HOPPERS
Seed Hopper
Disengage hopper latch and lift hopper off hopper support. Disconnect vacuum meter and drive connections.
