ROW UNIT CAbLE LIN
P/N A19399
Signal
Wire Gauge
Color
RM
MDM
SS
LIN
Power 24VDC
16
Red
3
1
-
3
Ground
16
Black
2
2
6
2
Power 12VDC
16
White
4
-
1
4
LIN
16
Blue
1
3
2
1
Seed Meter Motor
Driver Module (MDM)
LIN
Row Module (RM)
Seed Sensor (SS)
Motor Driver Module (MDM)
Motor (M)
P/N A19402
Signal
Wire Gauge
Color
MDM
M
Coil 1A+
18
Red
1
1
Coil 1B-
18
White
2
2
Coil 2A+
18
Green
3
3
Coil 2B-
18
Black
4
4
INSECTICIDE MOTOR CAbLE
