Kinze 4900 Front Folding Planter Rev. 5/14 - Manual (Page 10)

M0247-01 Model 4900
1-4 Rev. 5/14
TM
Specifications
Configuration Requirements*
24R without PTO pump option 54 gpm 6 SCV
24R with PTO pump option 37 gpm 4 SCV
16R without PTO pump option 47 gpm 6 SCV
16R with PTO pump option 37 gpm 4 SCV
12R without PTO pump option 46 gpm 6 SCV
12R with PTO pump option 37 gpm 4 SCV
*Add 4 gpm for fertlizer pump option
NOTE: Tractor-mounted PTO hydraulic pump supplies oil flow for Vacuum Meter hydraulic circuit.
NOTE: Power pack SCV should be set to maximum flow at all times.
NOTE: Tractor RPMs not recommended below 1750 RPMs.
Tractor Hydraulic Requirements
#1 SCV: Planter Lift
#2 SCV: Markers/Fold
#3 SCV: Weight Distribution/ASD/Fertilizer
#4 SCV: Power Pack/Hydraulic Drive
#5 & #6 SCV: Vacuum (PTO)
