14. SCANNER
REF.NO. CODE Q'TY DESCRIPTION REMARK
1 UH2790001 1 SCANNER UNIT ASSY A (SP)
2 UK2503000 1 SCN FLAT CABLE 6P
3 087321616 4TAPTITE, CUP S M3X16
4 UK2504001 1 SCN HARNESS 4P
MODEL HL-1260e 54T-U01-700
TI NO. 96-P018
15. FIXING UNIT, 120V/230V
REF.NO. CODE Q'TY DESCRIPTION SYMBOL REMARK
1-6 UH2791001 1 FIXING UNIT, 120V (SP)
1-6 UH2792001 1 FIXING UNIT, 230V (SP)
1 UH2793001 1 HEAT ROLLER (SP)
2 UH2608001 2 RETAINING RING, 25
3 UK2451001 1 FIXING PCB ASSY B48K142-200
4 085310815 1 TAPTITE, BIND B M3X8
5 UH2623001 1 PAPER DELIVERY ACTUATOR
6 UH2794001 1 HALOGEN HEATER, 120V (SP)
6 UH2795001 1 HALOGEN HEATER, 230V (SP)
7 087421015 2 TAPTITE, CUP S M4X10
8 UH2645001 2 HEATER SUPPORT SPRING S
9 UH2646001 2 HEATER SUPPORT SPRING S #2
10 UH2628001 1 THERMISTOR ASSY PT7
MODEL HL-1260e 54T-U01-770/771
T/I NO. PR97148, PR98054, PR98061
