1 . FEEDER UNIT
MODEL LT-1200/1600 54X -U01/U02 -630
REF.NO. CODE Q'TY DESCRIPTION REMARKS
1 UH2901001 1 FEEDER CHASSIS L ASSY
2 UH2952001 1 FEEDER CHASSIS R ASSY
3 UH2905000 1 STIFFENER PLATE UPPER
4 087320616 6 TAPTITE, CUP S M3X6
5 UH2906000 1 STIFFENER PLATE LOWER
6 087320616 4 TAPTITE, CUP S M3X6
7 UH2907000 1 FEEDER GUIDE
8 085310615 1 TAPTITE, BIND B M3X6
9 087320616 2 TAPTITE, CUP S M3X6
10 UH2954001 1 FEEDER ROLLER ASSY
11 UH2960000 2 BEARING S
12 048040346 2 RETAINING RING, E4
13 UH2362001 1 PAPER PICK-UP ROLLER ASSY
14 UH2364000 2 PAPER PICK-UP ROLLER COLLAR
15 048040346 1 RETAINING RING, E4
16 UH2967000 1 SPRING, EXTENSION
17 UH2357001 1 PAPER FEED MOTOR ASSY
18 087320616 2 TAPTITE, CUP S M3X6
19 UH2369001 1 PAPER PICK-UP SOLENOID
20 087320616 1 TAPTITE, CUP S M3X6
21 UH2911000 1 PAPER EMPTY SENSOR ACTUATOR
22 UH2381000 1 PE ACTUATOR LINK
23 UH2913000 1 FRONT COVER, GRAY1227
24 087320616 2 TAPTITE, CUP S M3X6
25 UH2918001 1 PAPER PATH FILM
26 UH2914000 1 SIDE COVER L, GRAY1227
27 087320616 4 TAPTITE, CUP S M3X6
28 UH2915000 1 SIDE COVER R, GRAY1227
29 087320616 5 TAPTITE, CUP S M3X6
30 UH2957000 1 FRONT STIFFENER CHASSIS
31 087320616 4 TAPTITE, CUP S M3X6
32 UH2958000 1 FRONT CHASSIS
33 087320616 4 TAPTITE, CUP S M3X6
34 UH2959000 1 GUIDE PLATE
PR99087
TI NO. PR99087
35 UH2356000 1 RELEASE PLATE L
36 UH2409000 1 RELEASE PLATE R
ADD
ADD
