I - 8
9 AC inlet
10 Face-up print delivery port
11 Fan outlet port
12 Rating label
13 Optional I/O slot
14 RS-232C interface connector
15 Centronics interface connector
16 Optional interface connector
4. PARTS OF THE PRINTER
4.1 External Views
1 Upper cover
2 Control panel
3 MP tray
4 Tray 1
5 Tray 2 (Option)
6 Font card slot
7 Font cartridge slot
8 Power switch
2
4
10
11
6
3
8
5
7
1
9
15
13
16
12
14
Figure 1.4
