Positions de la soupape à vide / gaz inerte, Raccordement du waste cube, If i – Heidolph Synthesis 1 User Manual
Page 128
128
I
F
I
2.4.1. Distributeur à 3 voies pour vide / gaz inerte (joint à la livraison)
Distributeur
à 3 voies
Garniture de
réaction Solid
Gaz inerte
Vide
Tuyaux à
vide
Bloc de
distribution (A)
Raccord vissé (B, C)
2.4.2. Positions de la soupape à vide / gaz inerte
Vide
Gaz inerte
Position de soupape
Gaz inerte
Position de
soupape Vide
2.5. Raccordement du Waste Cube
