101
E
RZ? ramp values, time
answer: RZ(x,y)=aaa,bbb,ccc,ddd,eee,fff,ggg,hhh,iii
Note: ramp number / zone need to be set before
x=ramp number,y=ramp zone
RT?
ramp values, temperature
answer: RT(x,y)=aaa,bbb,ccc,ddd,eee,fff,ggg,hhh,iii
Note: ramp number / zone need to be set before
x=ramp number,y=ramp zone
AP?
actual pressure
answer: AP=xxxx
b. Entry
SZn=xxxx! with n=1...4
nominal temperature, zone n
answer: SZn=xxx
SD=xxxx!
nominal rotational speed
answer: SD=xxxx
ST=xxx!
nominal time, timer elapse
answer: ST=xxx
SB=xxx!
operational status
answer: SB=xxx
Entry heater speed ramp active Identic
Bit b0 b1 b2 b3
SB=000! off off off off
SB=001! on off off off
SB=002! off on off off
SB=003! on on off off
SB=004! off off on off
SB=005! on off on off
SB=006! off on on off
SB=007! on on on off
SB=008! off off off on
SB=009! on off off on
SB=010! off on off on
SB=011! on on off on
SB=012! off off on on
SB=013! on off on on
SB=014! off on on on
SB=015! on on on on
RN=x!
ramp number
answer: RN=x
RR=x!
ramp zone
answer: RR=x x=1...4 zone 1...4
x=5 Identic
