Attachments
Residue pump (only on Distimatic including automatic drainage of residue)
Materials:
Head parts
PVDF
Diaphragm PTFE-coated
Valves FFPM
Resonating diaphragm PTFE
Condensate pump
Protection class
IP00
Power input 9 VA
Flow rate at atmospheric
pressure
Approx. 0.6 liter/min (measured with water at 20 °C)
Maximum suction height 3 mWS
Maximum pressure height 10 mWS
Total power 3500 W
Maximum permissible
medium temperature
5 - 80 °C
Materials:
Head parts
PVDF
Diaphragm PTFE-coated
Valves FFPM
Resonating diaphragm PTFE
Multiple switched socket (only on Hei-VAP)
Total power
3500 W
Measurements of multiple
socket excluding switch
unit (W x D x H)
520 mm x 84 mm x 50.5 mm (approx.)
Weight 1 kg (approx.)
Powerbox (only on Hei-VAP Industrial)
Dimensions (W x D x H)
150 x 150 x 125 mm (approx.)
Weight 3 kg (approx.)
Protection class IP54
Power input 9.5 VA
Connection Hei-VAP Industrial / chiller
Multiple socket (only on Hei-VAP Industrial)
Total power
3500 W
Dimensions (W x D x H) 262 mm x 59.3 mm x 43.9 mm
Weight 500 g (approx.)
Operating panel
Dimensions (W x D x H)
160 x 100 x 50 mm (approx.)
Weight 400 g (approx.)
Protection class IP65
Display Digital
Residue pump (only on Distimatic including automatic drainage of residue)
Dimensions (W x D x H)
110 x 161 x 191 mm (approx.)
Weight 1.5 kg (approx.)
Protection class IP65
Power input 300 VA
Flow rate with
atmospheric pressure
Approx. 2.6 liters/min (measured with water at 20 °C)
Maximum suction height 3 mWS
Maximum pressure height 10 mWS
Maximum permissible
medium temperature
5 - 80 °C
