Start-Up Start-Up
82 83
Parameter overview
Set parameters – Time-Mode
All parameters of the following table are settable. The settable criteria of a parameter
(parameter settings) are marked in the following with the symbols „>…<”.
Definition of a Step – One step consists of an evaporating flask refill along with an
evaporation time period.
Rule of thumb: the evaporating flask refills within approx. 20 ml / sec..
Definition of a Cycle – One cycle consists of numerous steps (to be set by operator).
After every cycle residue will be drained off.
Parameter Description
Start/stop To gain access to the menu.
Refill to start
initial filling
a. The key refill starts the pre-programmed operation.
b. The key parameter allows for pre-setting all
parameters.
Step
fill >…<
evap >…<
steps >…<
Pre-program steps
fill = enter time in minutes / seconds to refill evaporating
flask.
evap = enter time in minutes / seconds to evaporate. In this
time frame the flask is not refilled.
steps = enter number of steps to the final cycle.
Process stop after
>…< cycles
Enter the number of cycles for the process. After the last
cycle the system will power off.
Adjust pressure for
next cycle >…<
To drain residue the system will release vacuum and vent.
Enter the time in minutes / seconds your process requires
to reach the pre-programmed vacuum level again. After this
time frame the next cycle will start.
Drain time
cond >…<
resi >…<
Cond = Drainage of condensate
Please enter the required time to drain condensate from the
collector.
Resi = Drainage of residue
Please enter the required time to drain residue from the
evaporating flask.
ENDPROCESS
evaporate time >…<
Pre-program the time frame for the unit to power off all
periphery after the last cycle has been executed.
ENDPROCESS
drain time
cond >…<
resi >…<
Prior to powering off, the collector (condensate) and the
evaporating flask (residue) can be drained. You have the
option to allow for a final drainage (ON) or not (OFF).
Residue pump
during
process >…<
To drain the residue this option must be set ON.
Refill to start
initial filling
Start the process by pressing the refill key.
Overflow Collection
Vessel >…<
Activate the overflow power-off by pressing the ON key or
not (OFF).
Mo 09:00
2006-01-27
Date and time display format. Here you can set the current
date and time. Since error codes are always stamped with
time, we recommend you to keep the date up to date in
order to facilitate error analysis.
Drainage of condensate or residue can be performed manually by pressing the refill /
drain key (condensate) and drain residue key (residue).
