Installation Installation
20 21
Storage and transport
Additional on Distimatic including automatic drainage of residue:
Components Quantity Order number
Check valve for PTFE tube Ø 8 mm 1 11-300-006-67
Distributor from glassware set A
OR
Distributor from glassware set R
1
15-300-002-77
OR
15-300-002-76
Residue pump 1 14-300-010-40
3/2 way valve 1 11-300-004-97
PTFE tube Ø 8 mm (length 4 m) 1 23-30-01-03-15
Overflow sensor for condensate and residue
vessel
1 14-300-011-42
Hei-VAP Industrial Distimatic
Components Quantity Order number
Control box 1 11-300-004-89
Power cord 1
14-007-003-81 OR
14-007-005-45 OR
14-007-045-40 OR
14-007-009-36
(depending on your country)
Powerbox for Hei-VAP Industrial and
powerbox for chiller
(variant 3 x 400 V – 230 V, standard)
OR
Powerbox for Hei-VAP Industrial and
powerbox for chiller
(variant 1 x 230 V – 230 V)
2
11-300-007-01
OR
11-300-007-02
Multiple socket 1 14-300-010-50
Wall bracket 1 11-300-006-62
Operating panel 1 11-300-004-91
Check valve for PTFE tube Ø 6 mm 1 11-300-006-66
Valve matrix 1 11-300-004-93
Collector attachment 1 11-300-006-98
Control box attachment 1 11-300-007-07
Multiple screw connection with flask sensor 1 11-300-004-96
Screw cap 1 23-30-01-07-38
Cut-out sensor 1 11-300-004-98
Rubber ring Ø 80 mm for cut-out sensor 1 23-30-01-06-35
PTFE tube Ø 6 mm (length 10 m) 1 23-30-01-04-28
Filter 1 11-300-003-78
Hose connector T-type 1 23-30-01-05-74
Overflow sensor for condensate vessel 1 14-300-011-41
CAUTION Damages as a result of improper transport!
Damage can be caused to the device and the device mechanics in the
case of improper transport.
Avoid jolting and impacts.
WARNING Hot surfaces!
Risk of scalding and burns.
Allow the glass equipment to cool down.
Allow media to cool down.
WARNING Hazardous materials and solvents!
Dangers exist due to the emergence of hazardous substances and
solvents from inadequately sealed areas and the escaping of hazardous
substances into the atmosphere.
Ensure that no hazardous substances and solvents adhere to the
device components.
Store and transport the device in the original packaging.
Seal the packaging with adhesive tape.
Store the device in a dry location.
To carry the device, lift it from below.
Unpacking the device
CAUTION Damages as a result of improper transport!
Damage can be caused to the device and the device mechanics in the
case of improper transport.
Avoid jolting and impacts.
Unpack the device and if necessary, remove any protective films.
Check scope of supply.
Has the device been damaged or is delivery incomplete?
Contact Heidolph Instruments.
