Installation Device Description
Device description
The device is an automatic module, which is operated in combination with a rotary
evaporator. It has the following functions:
▪ Automatic distillation (permanent operation)
▪ Automatic refill into the evaporator
▪ Automatic discharge of condensate from the evaporator
▪ Automatic drainage of residue (only on Distimatic including automatic drainage of
residue)
▪ Automatic or manual termination of distillation
All the functions are available to you in automatic mode.
Scope of delivery
Hei-VAP Distimatic
Additional on Distimatic including automatic drainage of residue:
Components Quantity Order number
Control box 1 11-300-004-89
Power cord 1
14-007-003-81 OR
14-007-005-45 OR
14-007-045-40 OR
14-007-009-36
(depending on
your country)
Multiple switched socket 1 14-300-010-52
Wall bracket 1 11-300-006-62
Operating panel 1 11-300-004-91
Check valve for PTFE tube Ø 6 mm 1 11-300-006-66
Valve matrix 1 11-300-004-92
Multiple screw connection with flask
sensor
1 11-300-004-96
Screw cap 1 23-30-01-07-38
Cut-out sensor 1 11-300-004-98
Rubber ring Ø 120 mm for cut-out
sensor
1 23-30-01-06-35
PTFE tube Ø 6 mm (length 10 m) 1 23-30-01-04-28
Filter 1 11-300-003-78
Hose connector T-type 1 23-30-01-05-74
Overflow sensor for condensate
vessel
1 14-300-011-41
Components Quantity Order number
Check valve for PTFE tube Ø 8 mm 1 11-300-006-67
Condenser G9 1 514-00900-00
Residue pump 1 14-300-010-40
3/2 way valve 1 11-300-004-97
PTFE tube Ø 8 mm (length 4 m) 1 23-30-01-03-15
Overflow sensor for condensate
and residue vessel
1 14-300-011-42
Operation of Hei-VAP and Hei-VAP Industrial
See Hei-VAP or Hei-VAP Industrial operating instructions.
DANGER Danger when extinguishing fires!
Risk of serious injury as a result of chemical reactions.
Danger of chemical absorption.
Vigorous reactions with the medium can occur if water is used to
extinguish the fire.
Do NOT use water to put out the fire.
Use extinguishing agents which do not react with the medium.
Please observe the fire protection regulations and the fire
extinguishing instructions they provide.
