Installation Installation
40 41
Installation
The installation is described using the example of the Hei-VAP Distimatic including
automatic drainage of residue (glassware set G3 with condenser G9) and Hei-VAP
Industrial Distimatic including automatic drainage of residue (glassware set R).
Please refer to the chapter on „Explanation of the components” for the differences in
the glassware sets, multiple screw connection and the attaching of the cut-out sensor.
You can also find a list of the glassware sets below as far as their compatibility with the
respective order variant is concerned.
Installation/disassembly of Hei-VAP and Hei-VAP Industrial
See also the operating instructions of Hei-VAP or Hei-VAP Industrial.
Function principle of Distimatic
See chapter entitled „Function and connection principle” - „Distimatic
in general” - „Function principle of Distimatic”.
Hei-VAP glassware sets compatibility
Hei-VAP Industrial glassware sets compatibility
Order variant Glassware set
Distimatic including automatic drainage of
residue
Condenser G9
Distimatic without automatic drainage of
residue
G1
G3
G4
G6
Order variant Glassware set
Distimatic including automatic drainage of
residue
A, A2
R
Shorty R
Distimatic without automatic drainage of
residue
A, A2
R
Shorty R
Distimatic in general
WARNING Hazardous materials and solvents!
There are risks posed by the leakage of hazardous substances and
solvents from locations that are not properly sealed.
Check whether all screw caps have been tightened properly at the
threads to seal them off.
Check the device components for hazardous substances and
solvents.
Ensure that the separator for the power supply is easily accessible at
all times.
Cut off PTFE tubes, which are routed through an overflow sensor and
the multiple screw connection, with a cutting knife only at an angle
of approx. 45°.
When securing PTFE tubes to a connection, only cut them vertically
with the HOLEX hose cutter.
If you use other cutters, there is a danger that the
affected tube circuit could leak as a result of crushing
the tube.
WARNING
Unpacking and installation of the Automatic Module Distimatic should be
limited to and permitted only by Heidolph staff or authorized Heidolph
distributors only.
