Heidolph Automatic Module Distimatic User Manual
Page 20
Installation
Installation
38
39
Connection principle of the vacuum circuit
Connection principle of power supply
Reverse side
1
Vacuum fitting
Vacuum tube
1
1
Control box
2
Vacuum pump
3
Multiple socket
4
Residue pump
5
Powerbox for Hei-VAP Industrial
6
Powerbox for chiller
7
Chiller
8
Hei-VAP Industrial
Open wire ends, to be connected only by qualified personnel
Electrical cable
7
8
5
4
3
2
1
6
