Installation Installation
28 29
52 Multiple screw connection
53
Condenser G9 (only on Distimatic
including automatic drainage of residue)
54
Condenser from glassware set G3 (only
on Distimatic without automatic drainage
of residue)
55 Cut-out sensor
56 Hose connector T-type
57
3/2 way valve (only on Distimatic
including automatic drainage of residue)
58 Flask sensor
59
Screw cap GL32 (for use of condenser G9
without Distimatic)
60 Valve matrix
61 Evacuation valve
62 Condensate valve
63 Ventilation valve
64 Level sensor on collector
65 Collector
54 53
52
61 62 63
64
65
55
60
58
56
59
57
66
Multiple switched socket with connections
for Hei-VAP, chiller and residue pump
(total output = 3500 W)
67 Switch unit
66
67
Hei-VAP Distimatic
