EZWatch Evolution - Manual (Page 85)

list.
 Kill All Clients: Click on this button and then block all the clients logged in to your system.
Service:
 Server Status: Click on Start/Stop to turn on/off this option.
Options: Adjust the setting only when the server is stopped.
 Port: Assign a port for NCS System to connect Main Console system. Default port is 5170.
 Number of connections from NCS Servers that are allowed to connect to the system. The default is 8
NCS Servers and maximum is 16.
5.16 About Main Console
Go to About Main Console for detailed system and license information.
5.17 Video Source
(For system with MPEG4 capture device only, not supported under Lite license)
Step 1: Go to Video Source to adjust the Video Standard to NTSC or PAL.
Step 2: Adjust the maximum Video Resolution for all analog cameras.
Video Resolution Frame Rate Quality
Turbo mode Higher Lower
Standard mode Normal Normal
High Quality mode Lower Higher
Step 3: Click Sync all video signal level after pressing OK to synchronize video signal level to the optimized
display (Auto-gain control).
