Status Indicators

When power is applied to the ERn enclosure, the Paradigm repeater module LEDs located

on the front panel illuminate, indicating the status of the auxiliary power, LinkPower control

network, and connected stations.

The Aux Power and LinkPower LEDs indicate in green when the Paradigm station power

module is connected properly and auxiliary power and LinkPower are present. When there

is an unbalance in LinkPower the fault indicators illuminate. This condition typically means

that the station wiring is at fault, however it could mean a connected device is having an

issue. A qualified technician should inspect the system wire and terminations first, then

proceed to disconnecting devices to pinpoint the fault and correct it. The power supply will

update the fault indicators automatically when the fault condition is cleared.

If the NET A line has a fault (is shorted or has leakage to ground), the Fault + LED
lights.

If the NET B line has a fault (is shorted or has leakage to ground), the Fault - LED lights.

If neither fault LED is illuminated the data connections are properly installed and the
stations are receiving the data and power required for operation.
