14

Unison

®

ERn Rack Mount Enclosure Installation Manual

IEC Power Input Connector

ERn Rack Mount Enclosure Power Input

The ERn enclosures are available in 100-120, 230, and 240 VAC single phase

configurations. The ERn requires a single phase, 15A at 120 VAC or a 15A at 230 and 240

VAC input feed.

The ERn rack mount enclosure is provided with an IEC power input connector for easy and

convenient installation.

W A R N I N G :

All terminations must be done with the power off. Enclosures installed

without an accessible power disconnect device cannot be serviced or

operated safely.

AC Input

+

-

+

-

+

-

+

-

+

-

1A
1B
1A
1B
1A
1B
2A
2B
2A
2B
2A
2B

A+ A-

COM

B+B-

COM A+ A-

COM

B+B- COM

N

O

4

C

OM

4

N

O

3

C

OM

3

N

O

2

C

OM

2

N

O

1

C

OM

1

I

N

4

G

ND

I

N

3

G

ND

I

N

2

G

ND

I

N

1

G

ND

C

ONTACT

O

UT

C

ONTACT

I

N

DMX A

DMX

P

ASS

-T

HRU

DMX B

L

ON

A

UX

<

<

<

Ethernet

RS-232

serial

A rack mount ERn is supplied

with a full compliment of data

connections and an IEC

power connector on the rear

panel.

Lance and forms are provided

as a way to secure wiring with

wire ties.
